Failing to pay attention to the quality of your print circuit board design can present numerous challenges in the final processes. However, there are ways in which you can ease these expensive contingencies. One of those ways is to understand the design process and double-check the construction before investing your time and money in just any PCB manufacturer.
You don’t have to be involved in the process directly and know all the ins and outs, but a little more knowledge never hurts. Understanding these details only helps you better your decision-making. Besides, every professional must know what goes into their devices to maintain the quality and lifecycle of their end products.
Concept
Once you identify your need for a print circuit board, determine how it will perform, its features, and its placement in the end product. You must also be aware of the temperature range the board will operate in. It also helps to consider other environmental concerns.
Schematic
This is where the board is drawn based on the concept agreed upon. The diagram includes all the information on how each component will function appropriately in conjunction. The component value, rating, bill of materials, etc., are also listed and kept up-to-date for proper manufacturing.
Size
The PCB size and shape are usually the primary considerations to focus on. These two depend on the ultimate enclosure size, shape, and functionality. Today, PCB boards are getting smaller and smaller due to sleek devices, but this also complicates the process, and your chosen manufacturer must be able to accommodate your unique needs adequately.
Layers
The layers of the board will depend on the ultimate use. For example, there are two layers for toys, four layers for IoT products, six or more layers for smartphones, etc. So, you must provide the layering requirements to the manufacturer for precision designing. For end products that don’t have the space for larger boards, utilise a multi-layer mechanism. Layering adds to the production costs but is necessary to power up advanced functionalities.
Materials & Components
The items desired must be high-quality, easily accessible, and not sourced from elsewhere. So, take the time to discuss how the PCB company plans to obtain its materials while keeping costs competitive and the process time-efficient. Once all materials are gathered, their layout is prepared to make a precise circuit.
Mounting
Usually, there are two methods to place components on the board: Through-Hole and SMT. The through-hole technique involves manual fitting with components fitting through holes in the PCB and being soldered. However, SMT or Surface Mount Technology is fast, precise, electronic, and useful in mass manufacturing. If weight, size, and automation are your priorities, SMT PCB mounting is an efficient method to ensure quality and dependability.
Soldering
Soldering is what makes every component stick permanently to the board via a reflow oven. Now since every package comes with a distinct thermal profile, this must be taken care of thoroughly. When you choose a reliable and experienced manufacturer, they will work meticulously to avoid overheating and damaging the components.
Testing
This step ensures the components are not faulty and are soldered correctly. There can be different ways to check that every point meets your needs. Experienced PCB designers will conduct a series of tests through and through and make the necessary adjustments for accuracy.
Ready to Get Started? Get A Quote Today.
Understanding the design of the print circuit board helps determine what fits your needs the best. If you require the best quality print circuit boards for your upcoming project, we have the capabilities to meet your unique needs.
At Advanced Technology & Manufacturing, we are one of Western Australia’s best and most trusted PCB manufacturers offering full specs production services to all our clients. If you are looking for a premier PCB company near you, we can be the name to trust.
Our experts have the knowledge and experience to add value to your projects. Contact us to discuss your PCB manufacturing requirements and get a quote. We will be glad to help you with your project.
